mA - V Converter Z109UI2-1

Z1090UI2-1 is a voltage to current converter with 3-point isolation 1500 Vac and sensor power supply in 2-wire technique (20 Vdc stabilized, 20 mA max, protected against short circuit). Measurement and retransmission of the data is done on isolated analog output, with voltage output or in active/passive current. Through DIP-switches are selectable type of input, START-END, output mode (zero elevation, inversion, scale), output type (mA or V). Heir to the Z109UI2, Z109UI2-1 converter has on the front side the communication port in format Micro USB (replacing the 3.5 mm jack port). Through the Micro USB it is possible to configure the module not only via PC but also via mobile app “EASY Setup App”.

Talk to Our Experts Download Datasheet

  • Power supply: 9..40 Vdc, 19..28Vac 50- 60 Hz
  • Transducer power supply: 2 wires,20 Vdc stabilized, 20 mA maxprotected from short circuit
  • Input: voltage (bipolar)from 100 mV to 20 V in 9 scales),Current (bipolar up to 20 mA)

  • Sampling frequency/ Resolution: 240 sps(@11bit+sign) at 15 sps(@15bit+sign).
  • Operating temperature: - 10..60°C.
  • Isolation: 1,500 @3 points.
  • Configuration: By DIP switch, software (Windows PC), App (Android).
  • Connection: Micro USB port on the front of the module.
  • Certifications: CE, UL.

  • Power supply : 10-40 Vdc; 19-28 Vac
  • Max consumption : 1,6W (@24Vdc, 20mA output); 2,5W (max)
  • Power transducers : Yes, 2-wire, 20 Vdc stabilized, 20 mA max
